POSITION:HOME > PRODUCTS > ADVANCED COMPOSITES > Tepla® PEKK Tepla® PEKK Tepla® PEKK is a class of semi-crystalline thermoplastics with high heat resistance, chemical resistance and high mechanical load due to the high molecular weight of repeating units containing two ketone bonds and one ether bond in the main chain structure. Ability. Not only that, Tepla® PEKK series materials also exhibit excellent heat release, low smoke and low toxicity. Tepla® PEKK basic grades can be combined with glass fiber or carbon fiber to prepare modified materials to enhance their different properties. The corresponding materials can be used as high temperature resistant structural materials and electrical insulating materials. Highlights and Limitations Highlights: 1. Heat resistance characteristics; 2, chemical resistance; 3. Mechanical strength; 4, processing and molding; Limitations: 1. The output is small and the cost is high; 2, processing temperature is high; Tepla® PEKK performance comparison of different grades Tepla® PEKK is one of the high-temperature special materials. It shows similar performance data to PEEK to a certain extent, and has great advantages in high temperature resistance, wear resistance, chemical resistance, high strength and rigidity. The newly modified Tepla® PEKK from NFD engineers can help customers take cost savings, product quality and product performance to new heights. Not only that, NFD engineers have successfully developed some of the materials in this series into 3D printing materials, which can provide more space for your materials! The figure below is a comparison of the performance of Tepla® PEKK after adding 20%, 30%, 40% glass fiber modification. OVERVIEW Available materials:Total 12Available Area:America, Asia, Africa, Europe CONTACT US Tepla® PEKK Tepla® PEKK is a semi-crystalline thermoplastic with high heat resistance, chemical resistance and high mechanical load resistance. Tepla® PEKK itself is flame retardant, has excellent heat release, low smoke and low toxicity. Due to these characteristics, it exhibits excellent ablation characteristics. TYPE DESCRIPTION BASE MATERIAL TECHNICAL DATA ROHS REACH MSDS Tepla® T7200 Unreinforced Base Resin Tepla® PEKK View View View View Tepla® T7200 HF High Flow Tepla® PEKK View View View View Tepla® T7200 CF CL Carbon Fiber - Lubricated Tepla® PEKK View View View View Tepla® T7200 CF TF EC Carbon Fiber - PTFE - Electrically Conductive Tepla® PEKK View View View View Tepla® T7210CF Carbon Fiber 10% Tepla® PEKK View View View View Tepla® T7210GF Glass Fiber 10% Tepla® PEKK View View View View Tepla® T7220CF Carbon Fiber 20% Tepla® PEKK View View View View Tepla® T7220GF Glass Fiber 20% Tepla® PEKK View View View View Tepla® T7230CF Carbon Fiber 30% Tepla® PEKK View View View View Tepla® T7230GF Glass Fiber 30% Tepla® PEKK View View View View Tepla® T7235GF Glass Fiber 35% Tepla® PEKK View View View View Tepla® T7240CF Carbon Fiber 40% Tepla® PEKK View View View View NFD ADVANCED COMPOSITES 公司/COMPANY NFD can provide customized services to meet our customers’ differentiated demands by modifying these materials’ properties. The custom-tailored properties cover structural enhancement, electric conduction and electronic screening, flame retardancy, self-lubrication and wear resistance, long (short) carbon fiber reinforcement, long (short) glass fiber reinforcement(LFT), high specific gravity, low specific gravity, medical level quality, heat resistance, toughness, thermal conduction and electric insulation, electric and thermal conduction, laser marking, and magnetic detection. We can also provide nano-plastics, spraying-free plastics and special coloring services. And NFD will continue to honor our words by creating values for our customers with unique products and services. Home and Learn About All Products PRODUCTS SALES SALES INFORMATION East Asia(0.02M) Africa(0.02M) South America(0.02M) Europe(0.02M) North America(0.02M) PRODUCT FINDER FINDING YOUR NEED NFD Company provides large numbers of engineering plastic types and also mature material modification technologies which can meet the applications requiring properties. You can quickly find the materials that meet your product's capabilities here. Our fast delivery mechanism can make your creative ideas quickly become a reality. MORE Copyright © 2018 Jiangsu NFD Composites Co.,Ltd. 苏ICP备17051842号-1
